Getting Data on a Wave: Understanding QAM (Quadrature Amplitude Modulation)

In our recent webinar, we dove deep into a concept that often gets tossed around in Wi-Fi conversations but is rarely understood on a deeper level: Quadrature Amplitude Modulation, or QAM. If you’ve ever wondered how your favorite video stream arrives in 4K without buffering, or how files transfer so quickly across Wi-Fi, it all comes back to this foundational tech.

QAM isn’t just a term to memorize for certification exams—it’s the reason modern Wi-Fi is fast, flexible, and scalable. Understanding QAM gives you a better grip on how data moves through the air, why high-performance networks can struggle in certain environments, and where the future of wireless technology is headed.

Whether you’re a Wi-Fi pro, a curious network admin, or a tech enthusiast, this blog post builds on the insights shared in our QAM webinar and breaks it all down into digestible concepts you can apply. And yes, we’ll link to the full webinar so you can get the visuals and nerdy jokes too.

Key Takeaways from the Webinar

  • QAM enables high data throughput by encoding multiple bits per symbol.

  • Higher QAM levels require higher signal quality (SNR) and are more sensitive to interference.

  • The distance from the AP directly impacts whether high-QAM can be sustained.

  • QAM levels are always adapting in real-time based on environmental conditions.

  • Wi-Fi 7 introduces 4096-QAM, pushing modulation limits but requiring pristine conditions.

  • Amplitude reduction in higher-order QAM can significantly shrink coverage area.

  • Real-world environments often limit the usefulness of higher QAM levels.

  • It’s all about SNR—more than just power, precision matters.

What Is QAM, Anyway?

At its core, QAM is a method of modulating a radio wave to carry data. It does this by combining two modulation techniques:

  • Amplitude Modulation (AM): Varies the strength of the signal.

  • Phase Modulation (PM): Changes the position of the wave within its cycle.

By combining these two, QAM allows wireless devices to encode multiple bits of information into a single radio wave symbol. Think of it as giving a wave more "expression"—instead of just being loud or quiet (amplitude), or early/late (phase), it can be both.


The Constellation Analogy: Visualizing QAM

To understand QAM, imagine a dartboard where each point represents a unique combination of amplitude and phase. That’s your constellation diagram.

  • 4-QAM has 4 points (2 bits per symbol)

  • 16-QAM has 16 points (4 bits per symbol)

  • 64-QAM has 64 points (6 bits per symbol)

  • 256-QAM has 256 points (8 bits per symbol)

  • 1024-QAM has 1024 points (10 bits per symbol)

  • 4096-QAM in Wi-Fi 7 represents 12 bits per symbol

Each jump in QAM level increases the number of data bits that can be transmitted per symbol—but also makes those symbols more tightly packed in the constellation, meaning they’re harder to distinguish if there’s interference, noise, or signal degradation.

Think of it like whispering instructions during a rock concert—the more complex your message, the quieter your whisper, and the more you rely on the listener's ability to hear with precision. That's what high QAM asks of your wireless hardware.


Why Higher QAM = Higher Speed

In a perfect environment, increasing the QAM level means higher speeds. It’s that simple:

More bits per symbol = fewer symbols needed = faster transmission.

So why not use 4096-QAM all the time? Because real life isn’t perfect.

QAM relies on a high Signal-to-Noise Ratio (SNR) to distinguish the subtle differences between symbols. The more tightly packed the constellation points, the higher the risk that they’ll be misinterpreted if noise creeps in.

During the webinar, one attendee asked: how reasonable is it to get 4K-QAM in real-world environments? The answer: it’s not. Or rather, it’s only realistic in short-range, low-noise, high-performance scenarios—think right next to the AP, with minimal interference. Not across a warehouse or through several drywall partitions.

This is why high-QAM performance is often limited to close-proximity devices. When you step further from the AP or add interference, the system dynamically steps down to a lower QAM level to maintain reliability.


Diving into 1024-QAM: The Real-World Limits

One of the standout moments from the webinar was the discussion around 1024-QAM, which is standard in Wi-Fi 6. It’s capable of carrying 10 bits per symbol, which is powerful—but delicate.

Why? Because of amplitude levels.

A 1024-QAM constellation includes 10 different amplitude states, and those states are very close together. To distinguish between them, you need:

  • Highly accurate signal generation

  • Minimal distortion in the transmission path

  • High-performance receivers

To make matters more interesting, in order to generate these amplitude states, the transmitter may need to reduce power. For example, if an AP is transmitting at 10 dBm and one of the QAM states needs to represent 10% of that, the signal has to drop to 0 dBm for that specific symbol.

In other words: the AP is deliberately making its signal weaker to create amplitude variation. Which means reduced range.

That’s the paradox of QAM: higher performance, but in a much smaller coverage zone.


Wi-Fi Generations and QAM Evolution

Each new generation of Wi-Fi has pushed modulation boundaries:

  • Wi-Fi 4 (802.11n): Up to 64-QAM

  • Wi-Fi 5 (802.11ac): Up to 256-QAM

  • Wi-Fi 6/6E (802.11ax): Up to 1024-QAM

  • Wi-Fi 7 (802.11be): Up to 4096-QAM

The push toward higher QAM is driven by demand: more devices, more video, more cloud, more everything. But as we saw in the webinar chat, not everyone’s convinced we’ll see much benefit from 4096-QAM in the real world.

"I think we are going to start seeing some diminishing returns from QAM. So far the higher speeds are only achievable from close proximity to APs. Not always possible to achieve."

That's the trade-off. 4096-QAM may look impressive on spec sheets, but it won’t save your Zoom call if you're sitting across the office from the router in a noisy RF environment.


Understanding QAM in the Context of SNR

The webinar emphasized one golden rule: it’s all about SNR.

SNR—Signal-to-Noise Ratio—is the key metric that determines whether a high-QAM connection can be sustained. If your signal is weak or your environment is noisy, your AP and client devices will negotiate a lower QAM level to keep the connection reliable.

In practical terms, QAM performance comes down to:

  • Distance from the AP

  • Obstructions between devices

  • Interference from other wireless sources

  • Device quality and antenna performance

  • Transmit power and receiver sensitivity

Even your network layout and building materials can impact your SNR.

The best setup? High-density deployments with short client-to-AP distances, minimal interference, and modern hardware.


The Beauty of Modulation

Despite its challenges, many webinar attendees remarked on the elegance of QAM. Watching the modulation process—how bits translate to complex patterns in a constellation—was eye-opening.

"This explains why Wi-Fi 7 4k-QAM is so sensitive and can only be achieved in high SNR."

"It is beautiful actually."

"Best explanation of QAM I have ever seen."

Understanding QAM isn’t just about specs—it’s about appreciating the art of turning digital information into radio waves and back again, across the air, in real-time.


Final Thoughts: QAM and the Future

As Wi-Fi evolves, QAM will continue to be the backbone of faster, smarter networks. But it’s also a reminder that more is not always better—especially in wireless environments where noise, distance, and interference are everyday realities.

Still, understanding how QAM works gives us valuable insight into what we can expect from our networks—and what conditions we need to create for them to perform at their best.

The next time you see "1024-QAM" on a spec sheet, you’ll know exactly what it means, what it takes to achieve, and why it matters.


Want the Full Breakdown?

We covered all of this—and much more—in our recent webinar, complete with visuals, analogies, and live Q&A. Watch the full recording here and join us next time for more deep dives into the tech behind the signal.
